Formuler S Mini 4K

Formuler S mini 4k


Receptor satélite Android multimedia 4K UHD DVB-S2 & OTT-IPTV



Comprar Formuler S mini 4k a un precio increíble con el mejor servicio técnico y postventa

Precio final
109,00 €
Impuestos incluidos
TDT
  • No
  • + USB TDT DVB-T2
Gamepad / Joystick
  • No



Formuler S mini 4k


Receptor satélite multimedia 4K UHD DVB-S2 & OTT-IPTV



Receptor Satélite y Android con especificaciones Premium para el disfrute del contenido de DVB & OTT-IPTV. Nuevo Formuler esenciales con sintonizador de satélite UHD y las las mejores características para IPTV



Tuner & Channel Decoder(Satellite)
Input Connector F-type, IEC 169-24, Female
Frequency Range 950MHz ~ 2150MHz
Input Impedance 75Ω, unbalanced
Signal Level -65 to -25dBm
LNB Power 13/18VDC, max.400mA
22KHz Tone (22±2)KHz, (0.6±0.2)V
DISEqC Control V1.0/1.2/USALS Compatible
Demodulation QPSK / 8PSK
Input Symbol Rate 1 ~ 45 Ms/s (QPSK of DVB-S)
1 ~ 45 Ms/s (QPSK of DVB-S2)
FEC Decoder 1/2,3/5, 2/3, 3/4, 4/5,5/6,8/9,9.10 and 7/8 (QPSK)
3/5, 2/3, 3/4, 5/6, 8/9 and 9/10 (8PSK)
A/V Decoding
Video Decoding H.264/AVC BP/MP/HP@level 5.1, H.264/AVC MVC
H.265/HEVC Main/Main 10 profile@level 5.1 high-tier
AVS baseline profile@level 6.0, AVS-P16 (AVS+)
VC-1 SP@ML, MP@HL, AP@levels 0−3
Maximum 4K x 2K@60 fps 10-bit VP9 decoding
Input Rate Max. 108Mbit/s
Video Formats 4:3 Letter Box, 4:3 PanScan, 16 : 9
Video Resolution 720 x 576i, 720 x 480i, 1280 x 720p
1920 x 1080i, 1920 x 1080p, 2160p(4K x 2K)
Audio Decoding MPEG-1 Layer 1,2
AAC-LC and HE AAC V1/V2 decoding
Audio Mode Streo/Joint stereo/Mono
Sampling Rate 8khz to 192khz sampling rate
Main Sytem
Main Processor Hisilicon chipset
Memory eMMC : 8 GBytes
SDRAM : 1 GBytes (DDR4)
Audio / Video & Data IN/OUT
TV OUT Video & Audio Output
USB USB3.0, USB2.0
ETHERNET RJ45 connector, 10/100M Base
WiFi 802.11 b/g/n /  with internal antenna
Phone Jack CVBS Video Output, Audio L, R Output
Micro SD Card Micro SD Card Slot
IR Extension Removable IR extension
S/PDIF OPTIC
Front Panel
Slot 1 Smart Card Slot
Buttons 1 Buttons(Standby)
Indicators 1 Dual Color LED(Standby, Remote)
Power Supply
Input Voltage AC 100 ~ 240V, 50/60Hz
Type Adaptor
Power Consumption Max. 25W
Standby Power Max. 0.5W (Ultra low power)
Protection Separate Internal Fuse & Lighting protection







Compact Design

S mini-size features in an slim-compact design.

Small and unobtrusive, the new S mini packs a powerful punch in a small form factor.



Zero Lag

The pocket sized Formuler S mini delivers a powerful punch with its Quad-core CPU that delivers more than enough performance to run the amazing UHD satellite receiver & MYTVOnline IPTV middleware client.  Users will experience zero lag while interacting with even the most CPU intensive applications.



Supercharged modern interface

The most beautiful, modern and Innovative UX/UI Design Concepts are right here.

Seamless integration with Android system and native player



A Single, evolution of remote

The new Formuler RCU was specially designed and optimized for Satellite & IPTV.

Users can easily and quickly access desired menus,

and the RCU can be used with a variety of games and applications.

The power of Android IPTV is now in your hands



Cutting-edge features for watching TV on your terms

Advanced 7-day EPG Grid display

Catch-up TV - Easily find and watch missed programs with the click of a button

Video-on-Demand (VOD) / Support for multilingual audio and subtitle tracks

Fast channel zapping / Suitable for all ages / Parental controls



Enjoy Android apps from the comfort of your couch

Curated apps optimized for TV

Customizable markets available for system integrators and operators.



Play games with the wireless Formuler Game Controller

2.4GHz Wireless connectivity gives you the freedom to play games from anywhere in the room.  Precise directional-pad and dual analog joysticks allows users to master the most demanding games.  Powerful quad-core GPU makes 3D gaming possible.



Connect to share. Simple.

Miracast allows you to send content from your compatible phone, tablet or laptop straight to the TV with fast and simple content sharing.  Complicated connections are a thing of the past. Now you can enjoy your favorite content on your biggest screen.
